304 Stainless Steel Hotel Key Card Lock System: B020
YonAnn B020 B019 adopt 304 stainless steel material with acrylic in face panel to make it more generous .
- Three colors : silver , gold
- Material : 304 stainless steel material , 2.0mm thickness .
- 304 stainless steel panel and handles , stainless steel brushed , noble and fashion , also can keep long time for 5-6 years fadeless .
- The mortise lock adopt 5 latches , inside handle retracts latches and deadbolt .
- Datasheet
- Product Details
- Matched Mortise Lock
- Install Instagram Guide
| Model | B020 ,B019 |
| Colors | Gold, Silver, Light Gold |
| Material | 304 Stainless Steel |
| Voltage | 4 pcs AA Alkaline Battery |
| Card Chip | T5577/Mifare /ID |
| Door Thickness Requirement | 38mm – 65mm |
| Working Temperature | -20℃ – 65℃ |
| Brand Name | OEM |
| Warranty | 2 years |
| HS code | 8301400000 |
304 Stainless Steel Hotel Key Card Lock System Related Products
304 Stainless Steel Hotel Key Card Lock System
Features
YonAnn B020 & B019 adopt 304 stainless steel material with acrylic in face panel to make it more generous .
Three colors : silver , gold , light gold.
Material : 304 stainless steel material , 2.0mm thickness .
304 stainless steel panel and handles , stainless steel brushed , noble and fashion , also can keep long time for 5-6 years fadeless .
The mortise lock adopt 5 latches , inside handle retracts latches and deadbolt .
Technical data
Power voltage : DC6.0V , 4 PCS 5# AA alkaline battery supply .
Lower power alarm voltage : less than 4.8V , the lock will alarm to notice low battery .
Card support : ATMEL T5577 / Mifare 1
Working distance : 3cm~5cm
Working humidity : 20%~90%RH
Static Current : < 30uA
Hotel door lock software : offer free
Gross Wight : 2.9 kg
