Why Hotel Need Energy Saving Switch ?
Many people staying in hotels and guesthouses are used to taking away their room key card when they go out and then using a piece of cardboard into the card switch. So the room inside Electricals is still running, the lights are turning on , the air conditioner is still blowing, and the TV is working too though there is no one in the room at the moment. YonAnn energy saving switch is a special type of power saving switch that recognises the proximity card. This hotel card switch uses the hotel’s room card (your room card) as a card to take the electricity, if you insert any other card such as a bank card, ID card, bus card, business card, and paper etc, they can’t work. This can completely eliminate the waste of electricity when guests leave the room without turning off the power. Can be more effective in saving electricity for the hotel.
Different Function Energy Saving Switch
YonAnn energy saving switch has a more user-friendly design, which has two different types: one is a common one , all the hotel room cards can insert it to gain power .
Another one is time limited energy saving switches , which have more strict limits , only the valid room card can gain power , while the room card expires , or other room cards will can’t gain power for the room working, only work with the hotel door lock and the hotel door lock software , other door lock factories’s system can’t work .
Energy Saving Switch Features
- Special for hotel use
- Imported PC flame retardant material
- Energy saving switch delay about 16 seconds to disconnect the power
- Super power 40A
- Room unoccupied state LED indicator light.
Energy Saving Switch Technical Data
Name: Energy Saving Switch Size: 85*85mm
Colors: white, black, gold, silver Time Delay: 16S
Max Loading :6600W Voltage : 180V~250V
Material: Proofire PC Currenct: 40A
Install Hole Distance: 60mm between two screws
- Manufacturing
- Hotel Card Design
- Project Case
Workshop and Product Line
Hotel Card Design
Project Case
About YonAnn Energy Saving Switch
Special for hotel use
Our energy saving switch matched two types : work with temic card ( low frequency ) and Mifare 1 card ( high frequency ) , only the matched card can work on the card switch .
Also we have a time limited energy saving switch , which can only work with the valid room card. If the room card expires , it will can’t work on this lock to unlock the door .
Imported PC flame retardant material
The energy saving switch shell is made of imported PC flame retardant material can effective high temperature flame retardant with no deformation and no discoloration
Energy saving switch delay about 16 seconds to disconnect the power
Take away the room card about 16 seconds to disconnect the room electricity, air conditioning and lights can automatically turn off after the customers leave the room, which bring customers a better experience
Customers no need have to leave the room in a hurry, but also for the .hotel to save energy and electricity
Super power 40A
With 40A consumption, replace 30A/20A low power consumption.
Room unoccupied state LED indicator light.
The indicator light is soft and translucent, so that guests can easily find the switch after opening the room and entering the door.
Energy Saving Power Switch Wiring Diagram
- Please watch the wiring diagram below, professional electrician wiring is required, and please ensure that the power is disconnected when wiring.
- Break open the panel bezel by hand and go down to the central cover to operate the wiring work.
- Screw on the screws, close the cover to complete the wiring.
